720P LCOS Display 0.38 inch micro lcos display 1280x720 Overview: This Micro display module is composed of a LCOS display screen and a controller board. with a diagonal 0.38 inch size anda 1280 X720 high resolution.this lcos display can be powered directly via HDMI-A. If current from HDMI-A is not enough, it can also be powered by external supply. 0.38 inch lcos display parameter: ?Display Technology: Ferroelectric Liquid Crystal (FLC) on reflective CMOS ?Display Mode:Field sequential color ?Display Format:720p : 1280(H) x 720(V) ?Display Panel Active Area:8.448 x 4.752mm ?Display Area diagonal:9.693mm (0.38'') ?Input Grayscale:256 levels ?Color Depth:4.2Million unique colors (YCrCb video interface) ?Display Pixel Pitch:6.6um ?Display Frame Rate:60 Hz/360Hz (NTSC), 50/300 Hz (PAL) ?Brightness:200 cd/m2 Min. ?Contrast Ratio:150:1 (Typical) ?Digital Display Interface:YCbCr(4:2:2)-parallel (16 data, Hd, Vd, Clock) ?Storage Temperature:-30? ~ 83? 0.38 inch lcos display Features: ?The display module can reduce customer development time and cost. It has small volume and can be easily applied to customer product development and design. ?It uses FLCOS (Ferroelectric Liquid Crystal on Silicon) Display technology. ?Nice display color, high contrast ratio, low power consumption, low cost, clearer and more realistic display effect. ?Weight: About 5g (screen) ?Mode of work: Digital Mechanical Drawing Specification for Magnifier Eyepiece: 0.38 inch lcos display Applications: ?The electronic viewfinder of the digital camera / camera ?Portable civilian equipment such as micro projector, video glasses, head entertainment equipment, 3D display, game helmet and so on. ?Security monitoring, military use: single soldier helmet display, electronic sight, infrared night vision instrument, thermal imaging display, electronic telescope, aircraft helmet, gun sight, life detection visual device. ?Medical and industrial applications: man-machine visual engineering research, endoscopy, portable B-ultrasound, vision correction equipment, spectacles, various portable testing equipment ?Aero model: aerial, remote control aircraft parameter display system, remote control car video display terminal, etc. ?Minerals: coal exploration, metal mineral exploration Packing Including: 0.38" Micro lcos Display 1280x7200: 1 pcs Adapter HDMI Driver board:1 pcs Magnifier Eyepiece optics: 1pcs Adapter HDMI cable: 1pcs
