Store New Arrivals Add to Favorite View Feedback Contact 110V 120V 220V Wireless RF Remote Control Relay Switch Universal 2-Channel 433Mhz Receiver with 4 Pcs Transmitters for Garage Door Openers, Cars, LED Lights More (KR2202) Description Item model number KR2202+4KT05 Maximum Switching Voltage 220 Volts Color KR2202+4KT05?AC 85~220V 2-CH) Product Dimensions 1.18 x 0.98 x 0.79 inches Batteries 1 CR2032 batteries required. Item Weight 6.4 ounces Operation Mode Automatic Contact Type Normally Open The device has decent transmission distance and is quite flexible in functionality ,Signal stability ,Max range is up to 164ft/50m with no obstacle. 2CH Channel Wireless Remote Control , Adjustable working way, on/off. Switch Momentary/Toggle/Latched. All remote control switch kits support 433mhz frequency, by which it can delete the old code on the Relay Receiver Module and re-learn a new code when a remote control get lost, so you are always in control of it. The IC storage capacity on the controller is limited. Only 20 remote controllers can be stored. Applications from simple domestic remote control to autonomous control such as, Great for camper LED flood lights, remote trigger for a flame puffer ,entrance, Garage Doors, alarm system, lifting equipment and so on. NOTE: Please email us if you meet any problem, we are always here to help, thanks! Product Description Working mode:1.Momentary mode 2.Toggle mode3. Latching mode DC 12V 2 Channel Remote Control Switch Latching: applied to rolling doors, telescopic doors, etc., can be used with a 3-key remote control, using the latching mode, 1 key controls forward rotation, another key controls reverse rotation, and the other key no need to be pairing code, press it to pause the device. The same goes for the remote control with 4 keys. The other 2 keys no need to be pairing code, press any of the keys will stop the device from working. DC 12V 4 Channel Remote Control Switch Toggle:One remote control button controls one relay. The load end can be connected to 4 lamps or two motors. A total of 7 working modes: Momentary Mode Toggle Mode Latched Mode 2CH Momentary + 2CH Toggle 2CH Momentary + 2CH Latched 2CH Toggle + 2CH Latched 2CH Latched + 2CH Latched AC 85~220V 2 Channel Remote Control Switch Momentary: If work with a 2-button remote control, use the momentary mode, generally used to control switch, 2 channels can control 2 switches, but this situation is rare; It can also be used for motor equipment, rolling doors, curtains, etc. With a 2-button remote control, one button controls the forward rotation of the motor, and one button controls the reverse rotation of the motor. Release the remote control button and the device will stop. DC 6V~30V 2 Channel Remote Control Switch Latching: applied to rolling doors, telescopic doors, etc., can be used with a 3-key remote control, using the latching mode, 1 key controls forward rotation, another key controls reverse rotation, and the other key no need to be pairing code, press it to pause the device. The same goes for the remote control with 4 keys. The other 2 keys no need to be pairing code, press any of the keys will stop the device from working. Product Model Description(1202 2202 2402) 2CH Momentary Mode: Step 1, press the button on the receiver board once Step 2, press the A button, then the light of the receiver board will flash. Step 3, Wait for the blinking to finish, then press another button B. The receiver board will blink again. After pairing is complete, long press A button to control forward rotation and long press B button to control reverse rotation. 2CH Toggle mode: Step 1, press the button on the receiver board twice. Step 2, press the A button, then the light on the receiver board will blink. Step 3, wait for the blinking to end, then press the B button once more, and the receiver board will blink again. After the pairing is finished, short press the A button to control forward rotation and short press the B button to control reverse rotation. Short press the A/B button again, the motor will stop forward/reverse rotation. 2CH Latched mode: Step 1, press the button on the receiver board three times. Step 2, press the A button, then the light on the receiver board will blink. Step 3, wait for the blinking to end, then press the B button once more, and the receiver board will blink again. After the pairing is finished, short press A button to control forward rotation and short press B button to control reverse rotation. Press A+B button together, the motor stops rotating. You can also use other individual buttons to stop the rotation (except for the paired A and B buttons) KR1202 + 2KT09(DC 12V 2-CH Remote Control Switch) KR1204+2KT06(DC 12V 4-CH Remote Control Switch) KR2202+4KT05(AC 85~220V 2-CH Remote Control Switch) KR2402A+2KT06(DC 6V~30V 2-CH Remote Control Switch) ABOUT US We offer the best prices around on high quality products. Our E-store includes media such as books, movies, music and games while offering electronics, toys, sporting apparel, clothing, tools, general home, garden items and more. SHIPPING We are always working hard to ensure your package arrives as soon as possible. Please understand that some factors like weather, high postal traffic, and the performance of shipping companies are outside of our control. We offer free shipping to the lower 48 states and ship within 2 business days of payment, usually sooner. We do not accept P.O. Boxes. Please provide a physical address. For shipping outside of the continental USA, we only use's Global Shipping Program.The item is shipped to KY and then sent to the rest of the world. International customers are responsible for all duties and taxes. Continue to check out in order to calculate costs for shipping the item to your country. Messages regarding's Global Shipping Program MUST be directed at EXCLUSIVELY. RETURNS We offer a 30-Day Return Policy on items which you are not completely satisfied with. You have the option for a full-refund or an exchange of the item. No returns are available on items shipped outside of the USA. PAYMENT We accept PayPal. CONTACT US This page content is yet to come Please ad us to your favorite seller and visit again later Thank You CUSTOMER SATISFACTION We try our very best to make sure every customer is completely satisfied. If there's a problem, message us! We're happy to help. WE ACCEPT Copyright 2021 AutoDS. | All Rights Reserved
